Table of Direct-Set Arch Window Sizes Arch sizes on pages 84-99.

1
Scale ⁄8" (3) = 1'-0" (305) — 1:96
8'-7 1 ⁄4" 8'-10 7 ⁄16" 9'-3 1 ⁄4" 9'-11 1 ⁄4" 10'-6 1 ⁄8" 11'-3 1 ⁄4" 11'-11 1 ⁄4"
Window Dimension
(2623) (2704) (2826) (3029) (3203) (3435) (3639)
Minimum 8'-8" 8'-11" 9'-4" 10'-0" 10'-8" 11'-4" 12'-0"
Rough Opening (2642) (2718) (2845) (3048) (3251) (3454) (3658)
Unobstructed Glass 99 1 ⁄4" 102 7 ⁄16" 107 1 ⁄4" 115 1 ⁄4" 123 1 ⁄4" 131 1 ⁄4" 139 1 ⁄4"
(2521) (2602) (2724) (2927) (3131) (3334) (3537)
CUSTOM SIZES AVAILABLE
Window height Radius 120" (3048) 120" (3048) 120" (3048) 132" (3353) 144" (3658) 144" (3658)
shown in table Custom-size windows are available
Chord 11 11 ⁄16" 13 21 ⁄32" 15 7 ⁄8" 16 11 ⁄32" 16 7 ⁄8" 19 1 ⁄16"
1
Height 5'-10 15 ⁄16" (296) (1801) 6'-0 29 ⁄32" (347) (1852) 6'-3 1 ⁄8" (403) (1908) 6'-3 19 ⁄32" (415) (1920) 6'-4 1 ⁄8" (428) (1933) 6'-6 5 ⁄16" (485) (1989) in ⁄ 8" (3) increments. Contact your
Andersen supplier for more information.
(102)
Minimum Rough Opening = window height + 3 ⁄4" Unobstructed Glass = window height – 4" CUSTOM SIZES AVAILABLE 59 1 ⁄4" 63 1 ⁄4" (1505) (1607) 6'-2 15 ⁄16" (1903) ATAD8850* 6'-4 29 ⁄32" (1954) ATAD9450* 6'-7 1 ⁄8" (2009) ATAD10050* 6'-7 19 ⁄32" (2022) ATAD10850* 6'-8 1 ⁄8" (2035) ATAD11450* 6'-10 5 ⁄16" (2091) ATAD12050* Direct-set (ATAD) window sizes
(19)
Shoulder Height
shown. Use window dimensions and
minimum rough opening formula
shown for sash-set (ATA) window
sizes. For sash-set unobstructed
glass dimensions, see pages 98-101.

ATAD11454*
Grille patterns shown on page 109.

67 1 ⁄4" (1708) 6'-6 15 ⁄16" (2005) ATAD8854* 6'-8 29 ⁄32" (2055) ATAD9454* 6'-11 1 ⁄8" (2111) ATAD10054* 6'-11 19 ⁄32" (2123) ATAD10854* • "Window Dimension" always refers to outside frame to frame dimension. ATAD12054* Details shown on page 115.
• "Minimum Rough Opening" dimensions may need to be increased to allow for use of building
wraps, flashing, sill panning, brackets, fasteners or other items. See pages 236-237 for more details.
• Dimensions in parentheses are in millimeters.
*Tempered glass required. Some visual distortion may occur.
ATAD8858* ATAD9458* ATAD10058* ATAD10858*
Sash-Set Arch Window Unobstructed Glass Sash-Set Arch Window Unobstructed Glass Sash-Set Arch Window Unobstructed Glass
Dimensions and Area Specifications
Dimensions and Area Specifications
Dimensions and Area Specifications
71 1 ⁄4" (1810) 6'-10 15 ⁄16" (2106) Unobstructed Unobstructed (continued) Unobstructed Unobstructed Unobstructed Unobstructed
Glass
Window
Glass
Glass
Width
Number
Area
Number Glass Height Glass Window Glass Height Glass Window Glass Height Glass
Area
Area
Width
Width
Number
Inches/(mm) Inches/(mm) Sq. Ft./(m 2 ) Inches/(mm) Inches/(mm) Sq. Ft./(m 2 ) Inches/(mm) Inches/(mm) Sq. Ft./(m 2 )
ATAD8860* ATA2710 23 1 / 2 " (596) 7 7 / 8 " (201) 1.17 (0.11) ATA2930 25 1 / 2 " (647) 32 3 / 8 " (822) 5.58 (0.52) ATA3028 28 5 / 8 " (726) 29 3 / 16 " (742) 5.59 (0.52)
ATA2720 23 1 / 2 " (596) 19 7 / 8 " (505) 3.13 (0.29) ATA2910G 25 3 / 4 " (653) 8 7 / 16 " (214) 1.35 (0.13) ATA3030 28 5 / 8 " (726) 33 3 / 16 " (843) 6.38 (0.59)
ATA2724 23 1 / 2 " (596) 23 7 / 8 " (607) 3.78 (0.35) ATA2920G 25 3 / 4 " (653) 20 7 / 16 " (519) 3.50 (0.32) ATA3034 28 5 / 8 " (726) 37 3 / 16 " (945) 7.17 (0.67)
ATA2728 23 1 / 2 " (596) 27 7 / 8 " (709) 4.43 (0.41) ATA2924G 25 3 / 4 " (653) 24 7 / 16 " (621) 4.21 (0.39) ATA3038 28 5 / 8 " (726) 41 3 / 16 " (1047) 7.97 (0.74)
ATA2730 23 1 / 2 " (596) 31 7 / 8 " (810) 5.08 (0.47) ATA2928G 25 3 / 4 " (653) 28 7 / 16 " (722) 4.92 (0.46) ATA3040 28 5 / 8 " (726) 45 3 / 16 " (1148) 8.76 (0.81)
ATA2810 24 5 / 8 " (625) 8 3 / 16 " (207) 1.26 (0.12) ATA2930G 25 3 / 4 " (653) 32 7 / 16 " (824) 5.64 (0.52) ATA3044 28 5 / 8 " (726) 49 3 / 16 " (1250) 9.56 (0.89)
ATA2820 24 5 / 8 " (625) 20 3 / 16 " (512) 3.31 (0.31) ATA21010 26 5 / 8 " (675) 8 11 / 16 " (220) 1.43 (0.13) ATA3048 28 5 / 8 " (726) 53 3 / 16 " (1351) 10.35 (0.96)
ATA2824 24 5 / 8 " (625) 24 3 / 16 " (614) 3.99 (0.37) ATA21020 26 5 / 8 " (675) 20 11 / 16 " (525) 3.65 (0.34) ATA3050 28 5 / 8 " (726) 57 3 / 16 " (1453) 11.15 (1.04)
ATA2828 24 5 / 8 " (625) 28 3 / 16 " (715) 4.68 (0.43) ATA21024 26 5 / 8 " (675) 24 11 / 16 " (626) 4.38 (0.41) ATA3054 28 5 / 8 " (726) 61 3 / 16 " (1555) 11.94 (1.11)
ATA2830 24 5 / 8 " (625) 32 3 / 16 " (817) 5.36 (0.50) ATA21028 26 5 / 8 " (675) 28 11 / 16 " (728) 5.12 (0.48) ATA3058 28 5 / 8 " (726) 65 3 / 16 " (1656) 12.73 (1.18)
ATA2834 24 5 / 8 " (625) 36 3 / 16 " (919) 6.04 (0.56) ATA21030 26 5 / 8 " (675) 32 11 / 16 " (830) 5.86 (0.54) ATA3060 28 5 / 8 " (726) 69 3 / 16 " (1758) 13.53 (1.26)
ATA2838 24 5 / 8 " (625) 40 3 / 16 " (1020) 6.72 (0.62) ATA21034 26 5 / 8 " (675) 36 11 / 16 " (931) 6.60 (0.61) ATA3064 28 5 / 8 " (726) 73 3 / 16 " (1859) 14.32 (1.33)
ATA2840 24 5 / 8 " (625) 44 3 / 16 " (1122) 7.41 (0.69) ATA21038 26 5 / 8 " (675) 40 11 / 16 " (1033) 7.34 (0.68) ATA3068 28 5 / 8 " (726) 77 3 / 16 " (1961) 15.12 (1.40)
ATA2844 24 5 / 8 " (625) 48 3 / 16 " (1223) 8.09 (0.75) ATA21040 26 5 / 8 " (675) 44 11 / 16 " (1134) 8.08 (0.75) ATA3074 28 5 / 8 " 726) 85 3 / 16 " (2164) 16.71 1.55)
ATA2848 24 5 / 8 " (625) 52 3 / 16 " (1325) 8.77 (0.82) ATA21044 26 5 / 8 " (675) 48 11 / 16 " (1236) 8.82 (0.82) ATA3080 28 5 / 8 " (726) 93 3 / 16 " (2367) 18.29 (1.70)
ATA2850 24 5 / 8 " (625) 56 3 / 16 " (1427) 9.46 (0.88) ATA21048 26 5 / 8 " (675) 52 11 / 16 " (1338) 9.55 (0.89) ATA3110 29 1 / 2 " (749) 9 7 / 16 " (240) 1.70 (0.16)
ATA2854 24 5 / 8 " (625) 60 3 / 16 " (1528) 10.14 (0.94) ATA21050 26 5 / 8 " (675) 56 11 / 16 " (1439) 10.29 (0.96) ATA3120 29 1 / 2 " (749) 21 7 / 16 " (545) 4.16 (0.39)
ATA2858 24 5 / 8 " (625) 64 3 / 16 " (1630) 10.82 (1.01) ATA21054 26 5 / 8 " (675) 60 11 / 16 " (1541) 11.03 (1.02) ATA3124 29 1 / 2 " (749) 25 7 / 16 " (647) 4.97 (0.46)
ATA2860 24 5 / 8 " (625) 68 3 / 16 " (1731) 11.51 (1.07) ATA21058 26 5 / 8 " (675) 64 11 / 16 " (1642) 11.77 (1.09) ATA3128 29 1 / 2 " (749) 29 7 / 16 " (748) 5.79 (0.54)
ATA2864 24 5 / 8 " (625) 72 3 / 16 " (1833) 12.19 (1.13) ATA21060 26 5 / 8 " (675) 68 11 / 16 " (1744) 12.51 (1.16) ATA3130 29 1 / 2 " (749) 33 7 / 16 " (850) 6.61 (0.61)
ATA2868 24 5 / 8 " (625) 76 3 / 16 " (1935) 12.87 (1.20) ATA21064 26 5 / 8 " (675) 72 11 / 16 " (1846) 13.25 (1.23) ATA3210 30 5 / 8 " (777) 8 15 / 16 " (227) 1.68 (0.16)
ATA2874 24 5 / 8 " (625) 84 3 / 16 " (2138) 14.24 (1.32) ATA21068 26 5 / 8 " (675) 76 11 / 16 " (1947) 13.99 (1.30) ATA3220 30 5 / 8 " (777) 20 15 / 16 " (532) 4.23 (0.39)
ATA2880 24 5 / 8 " (625) 92 3 / 16 " (2341) 15.61 (1.45) ATA21074 26 5 / 8 " (675) 84 11 / 16 " (2150) 15.46 (1.44) ATA3224 30 5 / 8 " (777) 24 15 / 16 " (634) 5.08 (0.47)
ATA2910 25 1 / 2 " (647) 8 3 / 8 " (213) 1.33 (0.12) ATA21080 26 5 / 8 " (675) 92 11 / 16 " (2354) 16.94 (1.57) ATA3228 30 5 / 8 " (777) 28 15 / 16 " (735) 5.93 (0.55)
ATA2920 25 1 / 2 " (647) 20 3 / 8 " (518) 3.45 (0.32) ATA3010 28 5 / 8 " (726) 9 3 / 16 " (234) 1.61 (0.15) ATA3230 30 5 / 8 " (777) 32 15 / 16 " (837) 6.78 (0.63)
ATA2924 25 1 / 2 " (647) 24 3 / 8 " (619) 4.16 (0.39) ATA3020 28 5 / 8 " (726) 21 3 / 16 " (539) 4.00 (0.37)
• Dimensions in parentheses are in millimeters or square meters. Specialty Windows
ATA2928 25 1 / 2 " (647) 28 3 / 8 " (721) 4.87 (0.45) ATA3024 28 5 / 8 " (726) 25 3 / 16 " (640) 4.79 (0.45)
