Page 105 - Andersen Architectural Collection A-Series 2018-19 Product Guide for Professionals

A-SERIES

Notes on page 110 also apply to this page. Springline ™ sizes on pages 102-112.

3'-7 1 ⁄4" 3'-11 1 ⁄4" 4'-3 1 ⁄4" 4'-7 1 ⁄4" 4'-11 1 ⁄4" 5'-3 1 ⁄4" 5'-7 1 ⁄4" 5'-11 1 ⁄4"
(1099) (1200) (1302) (1403) (1505) (1607) (1708) (1810)
3'-8" 4'-0" 4'-4" 4'-8" 5'-0" 5'-4" 5'-8" 6'-0"
(1118) (1219) (1321) (1422) (1524) (1626) (1727) (1829)
39 1 ⁄4" 43 1 ⁄4" 47 1 ⁄4" 51 1 ⁄4" 55 1 ⁄4" 59 1 ⁄4" 63 1 ⁄4" 67 1 ⁄4"
(997) (1099) (1200) (1302) (1403) (1505) (1607) (1708)
21 5 ⁄8" (549) 23 5 ⁄8" (600) 25 5 ⁄8" (651) 27 5 ⁄8" (702) 29 5 ⁄8" (752) 31 5 ⁄8" (803) 33 5 ⁄8" (854) 35 5 ⁄8" (905)

21 5 ⁄8" (549) 23 5 ⁄8" (600) 25 5 ⁄8" (651) 27 5 ⁄8" (702) 29 5 ⁄8" (752) 31 5 ⁄8" (803) 33 5 ⁄8" (854) 35 5 ⁄8" (905)

2'-3 7 ⁄8" (708) 2'-5 7 ⁄8" (759) 2'-7 7 ⁄8" (810) 2'-9 7 ⁄8" (860) 2'-11 7 ⁄8" (911) 3'-1 7 ⁄8" (962) 3'-3 7 ⁄8" (1013) 3'-5 7 ⁄8" (1064)

ATSD3807 ATSD4007 ATSD4407 ATSD4807 ATSD5007 ATSD5407 ATSD5807 ATSD6007

2'-8 7 ⁄8" (835) 2'-10 7 ⁄8" (886) 3'-0 7 ⁄8" (937) 3'-2 7 ⁄8" (987) 3'-4 7 ⁄8" (1038) 3'-6 7 ⁄8" (1089) 3'-8 7 ⁄8" (1140) 3'-10 7 ⁄8" (1191)

ATSD3810 ATSD4010 ATSD4410 ATSD4810 ATSD5010 ATSD5410 ATSD5810 ATSD6010

3'-8 7 ⁄8" (1140) 3'-10 7 ⁄8" (1191) 4'-0 7 ⁄8" (1241) 4'-2 7 ⁄8" (1292) 4'-4 7 ⁄8" (1343) 4'-6 7 ⁄8" (1394) 4'-8 7 ⁄8" (1445) 4'-10 7 ⁄8" (1495)

ATSD3820 ATSD4020 ATSD4420 ATSD4820 ATSD5020 ATSD5420 ATSD5820 ATSD6020

4'-0 7 ⁄8" (1241) 4'-2 7 ⁄8" (1292) 4'-4 7 ⁄8" (1343) 4'-6 7 ⁄8" (1394) 4'-8 7 ⁄8" (1445) 4'-10 7 ⁄8" (1495) 5'-0 7 ⁄8" (1546) 5'-2 7 ⁄8" (1597)

ATSD3824 ATSD4024 ATSD4424 ATSD4824 ATSD5024 ATSD5424 ATSD5824 ATSD6024

4'-4 7 ⁄8" (1343) 4'-6 7 ⁄8" (1394) 4'-8 7 ⁄8" (1445) 4'-10 7 ⁄8" (1495) 5'-0 7 ⁄8" (1546) 5'-2 7 ⁄8" (1597) 5'-4 7 ⁄8" (1648) 5'-6 7 ⁄8" (1699)

ATSD3828 ATSD4028* ATSD4428* ATSD4828* ATSD5028 ATSD5428 ATSD5828 ATSD6028

4'-8 7 ⁄8" (1445) 4'-10 7 ⁄8" (1495) 5'-0 7 ⁄8" (1546) 5'-2 7 ⁄8" (1597) 5'-4 7 ⁄8" (1648) 5'-6 7 ⁄8" (1699) 5'-8 7 ⁄8" (1749) 5'-10 7 ⁄8" (1800)

ATSD3830 ATSD4030 ATSD4430 ATSD4830 ATSD5030 ATSD5430 ATSD5830 ATSD6030

5'-0 7 ⁄8" (1546) 5'-2 7 ⁄8" (1597) 5'-4 7 ⁄8" (1648) 5'-6 7 ⁄8" (1699) 5'-8 7 ⁄8" (1749) 5'-10 7 ⁄8" (1800) 6'-0 7 ⁄8" (1851) 6'-2 7 ⁄8" (1902)

ATSD3834 ATSD4034 ATSD4434 ATSD4834 ATSD5034 ATSD5434 ATSD5834 ATSD6034

5'-4 7 ⁄8" (1648) 5'-6 7 ⁄8" (1699) 5'-8 7 ⁄8" (1749) 5'-10 7 ⁄8" (1800) 6'-0 7 ⁄8" (1851) 6'-2 7 ⁄8" (1902) 6'-4 7 ⁄8" (1953) 6'-6 7 ⁄8" (2003)

ATSD3838 ATSD4038 ATSD4438 ATSD4838 ATSD5038 ATSD5438 ATSD5838 ATSD6038
continued on next page

• "Window Dimension" always refers to outside frame to frame dimension.
• "Minimum Rough Opening" dimensions may need to be increased to allow for use of building wraps, flashing, sill panning, brackets, fasteners or other items. See pages 236-237 for more details.
• Dimensions in parentheses are in millimeters. Specialty Windows
