SPECIALTY WINDOWS
™
Table of Direct-Set Springline Window Sizes Notes on page 110 also apply to this page.
1
Scale ⁄8" (3) = 1'-0" (305) — 1:96
1'-7 1 ⁄4" 1'-11 1 ⁄4" 2'-3 1 ⁄4" 2'-5 1 ⁄4" 2'-7 1 ⁄4" 2'-9 1 ⁄4" 2'-11 1 ⁄4" 3'-1 1 ⁄4" 3'-3 1 ⁄4"
Window Width Dimension
(489) (591) (692) (743) (794) (845) (895) (946) (997)
Minimum 1'-8" 2'-0" 2'-4" 2'-6" 2'-8" 2'-10" 3'-0" 3'-2" 3'-4"
Rough Opening (508) (610) (711) (762) (813) (864) (914) (965) (1016)
Unobstructed Glass 15 1 ⁄4" 19 1 ⁄4" 23 1 ⁄4" 25 1 ⁄4" 27 1 ⁄4" 29 1 ⁄4" 31 1 ⁄4" 33 1 ⁄4" 35 1 ⁄4"
(387) (489) (591) (641) (692) (743) (794) (845) (895)
CUSTOM SIZES AVAILABLE
Window height Radius 9 5 ⁄8" (244) 11 5 ⁄8" (295) 13 5 ⁄8" (346) 14 5 ⁄8" (371) 15 5 ⁄8" (397) 16 5 ⁄8" (422) 17 5 ⁄8" (448) 18 5 ⁄8" (473) 19 5 ⁄8" (498)
shown in table
Chord 16 5 ⁄8" (422) 17 5 ⁄8" (448) 18 5 ⁄8" (473) 19 5 ⁄8" (498)
Height 6 1 ⁄4" (159) 1'-3 7 ⁄8" 9 5 ⁄8" (244) (403) 11 5 ⁄8" 1'-5 7 ⁄8" (295) (454) 1'-7 7 ⁄8" 13 5 ⁄8" (346) (505) 14 5 ⁄8" 1'-8 7 ⁄8" (371) (530) 15 5 ⁄8" 1'-9 7 ⁄8" (397) (556) 1'-10 7 ⁄8" (581) 1'-11 7 ⁄8" (606) 2'-0 7 ⁄8" (632) 2'-1 7 ⁄8" (657)
Minimum Rough Opening = window height + 3 ⁄4" Unobstructed Glass = window height – 4" CUSTOM SIZES AVAILABLE Shoulder Height 11 1 ⁄4" 23 1 ⁄4" (286) (591) 1'-8 7 ⁄8" 2'-8 7 ⁄8" ATSD1807 1'-10 7 ⁄8" 2'-10 7 ⁄8" ATSD2007 2'-0 7 ⁄8" 3'-0 7 ⁄8" ATSD2407 2'-1 7 ⁄8" 3'-1 7 ⁄8" ATSD2607 2'-2 7 ⁄8" 3'-2 7 ⁄8" ATSD2807 2'-3 7 ⁄8" 3'-3 7 ⁄8" ATSD21007 2'-4 7 ⁄8" 3'-4 7 ⁄8" (733) (1038) ATSD3007 2'-5 7 ⁄8" 3'-5 7 ⁄8" (759) (1064)
(102)
(19)
(708)
(657)
(683)
(530)
(581)
(632)
ATSD3010
ATSD2010
ATSD21010
ATSD1810
ATSD2410
ATSD3410
ATSD2810
ATSD3210
ATSD2610
(1013)
(987)
(937)
(962)
(886)
(835)
(1114)
(1064)
(1038)
(1089)
(937)
(987)
27 1 ⁄4" (692) 3'-0 7 ⁄8" ATSD1820 3'-2 7 ⁄8" ATSD2020 3'-4 7 ⁄8" ATSD2420 3'-5 7 ⁄8" ATSD2620 3'-6 7 ⁄8" ATSD2820 3'-7 7 ⁄8" ATSD21020 3'-8 7 ⁄8" (1140) ATSD3020 3'-9 7 ⁄8" (1165) ATSD3220 3'-10 7 ⁄8" (1191) ATSD3420
ATSD1824 ATSD2024 ATSD2424 ATSD2624 ATSD2824 ATSD21024 ATSD3024 ATSD3224 ATSD3424
31 1 ⁄4" (794) 3'-4 7 ⁄8" (1038) 3'-6 7 ⁄8" (1089) 3'-8 7 ⁄8" (1140) 3'-9 7 ⁄8" (1165) 3'-10 7 ⁄8" (1191) 3'-11 7 ⁄8" (1216) 4'-0 7 ⁄8" (1241) 4'-1 7 ⁄8" (1267) 4'-2 7 ⁄8" (1292)
ATSD1828 ATSD2028 ATSD2428 ATSD2628 ATSD2828 ATSD21028 ATSD3028 ATSD3228 ATSD3428
35 1 ⁄4" (895) 3'-8 7 ⁄8" (1140) 3'-10 7 ⁄8" (1191) 4'-0 7 ⁄8" (1241) 4'-1 7 ⁄8" (1267) 4'-2 7 ⁄8" (1292) 4'-3 7 ⁄8" (1318) 4'-4 7 ⁄8" (1343) 4'-5 7 ⁄8" (1368) 4'-6 7 ⁄8" (1394)
ATSD1830 ATSD2030 ATSD2430 ATSD2630 ATSD2830 ATSD21030 ATSD3030 ATSD3230 ATSD3430
39 1 ⁄4" (997) 4'-0 7 ⁄8" (1241) 4'-2 7 ⁄8" (1292) 4'-4 7 ⁄8" (1343) 4'-5 7 ⁄8" (1368) 4'-6 7 ⁄8" (1394) 4'-7 7 ⁄8" (1419) 4'-8 7 ⁄8" (1445) 4'-9 7 ⁄8" (1470) 4'-10 7 ⁄8" (1495)
ATSD1834 ATSD2034 ATSD2434 ATSD2634 ATSD2834 ATSD21034 ATSD3034 ATSD3234 ATSD3434
43 1 ⁄4" (1099) 4'-4 7 ⁄8" (1343) 4'-6 7 ⁄8" (1394) 4'-8 7 ⁄8" (1445) 4'-9 7 ⁄8" (1470) 4'-10 7 ⁄8" (1495) 4'-11 7 ⁄8" (1521) 5'-0 7 ⁄8" (1546) 5'-1 7 ⁄8" (1572) 5'-2 7 ⁄8" (1597)
ATSD1838 ATSD2038 ATSD2438 ATSD2638 ATSD2838 ATSD21038 ATSD3038 ATSD3238 ATSD3438
• "Window Dimension" always refers to outside frame to frame dimension.
• "Minimum Rough Opening" dimensions may need to be increased to allow for use of building wraps, flashing, sill panning, brackets, fasteners or other items. See pages 236-237 for more details.
• Dimensions in parentheses are in millimeters.
