Page 59 - Andersen Architectural Collection A-Series 2018-19 Product Guide for Professionals

A-SERIES

Transom sizes on pages 56-60.

4'-3 1 /4" 4'-7 1 /4" 4'-11 1 /4" 5'-3 1 /4" 5'-7 1 /4" 5'-11 1 /4"
(1302) (1403) (1505) (1607) (1708) (1810)
4'-4" 4'-8" 5'-0" 5'-4" 5'-8" 6'-0"
(1321) (1422) (1524) (1626) (1727) (1829)
44 5 /8" 48 5 /8" 52 5 /8" 56 5 /8" 60 5 /8" 64 5 /8"
(1133) (1335) (1337) (1438) (1540) (1641)

1
Custom-size windows are available in ⁄ 8" (3)
ATF4410 ATF4810 ATF5010 ATF5410 ATF5810 ATF6010
increments. See page 69 for custom sizes and
specifications.
ATF4414 ATF4814 ATF5014 ATF5414 ATF5814 ATF6014
ATV4414 ATV4814 ATV5014 ATV5414 ATV5814 ATV6014

ATF4416 ATF4816 ATF5016 ATF5416 ATF5816 ATF6016 Venting Transom Stationary
Venting
ATV4416 ATV4816 ATV5016 ATV5416 ATV5816 ATV6016

Stationary
ATF4418 ATF4818 ATF5018 ATF5418 ATF5818 ATF6018 Venting Fixed Transom
Choose venting (ATV) or fixed (ATF).
ATV4418 ATV4818 ATV5018 ATV5418 ATV5818 ATV6018
Venting window must be installed to vent as
ATF44110 ATF48110 ATF50110 ATF54110 ATF58110 ATF60110 shown and should not be rotated and used
as a hopper.
ATV44110 ATV48110 ATV50110 ATV54110 ATV58110 ATV60110
Details shown on page 63. Grille patterns
shown on page 62.
ATF4420 ATF4820 ATF5020 ATF5420 ATF5820 ATF6020

ATV4420 ATV4820 ATV5020 ATV5420 ATV5820 ATV6020 Transom Windows
A-Series

ATF4422 ATF4822 ATF5022 ATF5422 ATF5822 ATF6022

ATV4422 ATV4822 ATV5022 ATV5422 ATV5822 ATV6022

ATF4424 ATF4824 ATF5024 ATF5424 ATF5824 ATF6024

ATV4424 ATV4824 ATV5024 ATV5424 ATV5824 ATV6024

ATF4426 ATF4826 ATF5026 ATF5426 ATF5826 ATF6026

ATV4426 ATV4826 ATV5026 ATV5426 ATV5826 ATV6026

• "Window Dimension" always refers to outside frame to frame
ATF4428 ATF4828 ATF5028 ATF5428 ATF5828 ATF6028 dimension.
• "Minimum Rough Opening" dimensions may need to be increased
to allow for use of building wraps, flashing, sill panning, brackets,
fasteners or other items. See pages 236-237 for more details.
• Dimensions in parentheses are in millimeters.
ATV4428 ATV4828 ATV5028 ATV5428 ATV5828 ATV6028
continued on next page
