Page 152 - Andersen Architectural Collection E-Series 2017-18 Product Guide for Professionals

French Gliding Patio Door Sizes

NOTES
1
7' 8 /4"
1
2' 8 /2" 5' 0 1 /4" All doors and sidelights use safety/
2' 8" 4' 11 3 /4" 7' 7 3 /4"
R.O. F .S. tempered glass.
Use structural joining material when
necessary or required by code.
The light patterns illustrated apply to
6' 8 1 /2" 6' 8" removable interior wood grilles, Full Divided
Light, Simulated Divided Light, Decorelle
100, 150 and 400 and Finelight Grilles-
™
Between-the-Glass. All removable interior
wood grilles will be installed in the units
unless otherwise specified.
FGP2668S FGP5068 LS,SR FRS7668-OX-O or O-XO
For a metric conversion in millimeters,
multiply dimensions in inches by 25.4.
6' 10 1 /2" 6' 10" FORMULA FOR COMBINATION DOORS
The overall frame dimension (both width and
height) is equal to the sum of the individual
unit frame dimensions plus joining material
dimension(s).
FGP26610S FGP50610 LS,SR FRS76610-OX-O or O-XO
The overall rough opening (both width
and height) is equal to the overall frame
dimensions plus 1/4" on all sides.
8' 0 1 /2" 8' 0"
FGP2680S FGP5080 LS,SR FRS7680-OX-O or O-XO

French Gliding Patio Door Sizes

1
1
1
3' 2 /2" 6' 0 /4" 9' 2 /4"
3' 2" 5' 11 /4" 9' 1 /4"
3
3
R.O.
F .S.
6' 8 1 /2" 6' 8"
FGP3068S FGP6068 LS,SR FRS9068-OX-O or O-XO

6' 10 1 /2" 6' 10"

FGP30610S FGP60610 LS,SR FRS90610-OX-O or O-XO

8' 0 1 /2" 8' 0"

FGP3080S FGP6080 LS,SR FRS9080-OX-O or O-XO

150
CUSTOM SIZES ARE AVAILABLE. CONTACT YOUR LOCAL SUPPLIER FOR MORE INFORMATION. DRAWINGS ARE NOT TO SCALE.
