4-Panel Gliding Patio Door Sizes

11' 10 /4" 15' 10 /4"
3
3
1
11' 10 /4" 15' 10 /4"
1
R.O. F .S. R.O. F .S.
6' 8 1 /2" 6' 8" 6' 8 1 /2" 6' 8"

4PGP16068**

6' 10 1 /2" 6' 10" 6' 10 1 /2" 6' 10"

4PGP160610**

8' 0 1 /2" 8' 0" 8' 0 1 /2" 8' 0"

4PGP16080**
Gliding Patio Door Direct-Set Elliptical Sizes (Specialty Frame)

1
1
1
1
5' 0 /4" 6' 0 1 /4" 7' 8 /4" 8' 0 /4" 9' 2 /4"
3
3
3
4' 11 /4" 5' 11 3 /4" 7' 7 3 /4" 7' 11 /4" 9' 1 /4"
R.O. R.O.
F.S. F.S.
1' 4 1 /2" 1' 4" TE 4' 11 /4" X 1' 4" TE 5' 11 /4" X 1' 4" 1' 6 1 /2" 1' 6" TE 7' 7 /4" X 1' 6" TE 7' 11 3 /4" X 1' 6" TE 9' 1 /4" X 1' 6"
3
3
3
3
Gliding Patio Door Direct-Set Transom Sizes (Specialty Frame)
1
1
1
1
1
5' 0 /4" 6' 0 /4" 7' 8 /4" 8' 0 /4" 9' 2 /4"
4' 11 /4" 5' 11 3 /4" 7' 7 /4" 7' 11 /4" 9' 1 /4"
3
3
3
3
R.O. F.S.
2' 0 1 /2" 2' 0"
TR 4' 11 /4" x 2' 0" TR 5' 11 /4" x 2' 0" TR 7' 7 3 /4" x 2' 0" TR 7' 11 3 /4" x 2' 0" TR 9' 1 /4" x 2' 0"
3
3
3
NOTES
All doors and sidelights use safety/tempered glass.
If glass is positioned within 18" of the finished floor, safety/tempered glass may be required. Local codes may differ. Verify tempered glass requirements
with your local building code official.
Astragal is applied to third panel from the left (as viewed from the exterior) on a 4-panel gliding patio door.
**4-panel doors are shipped knocked down and require field assembly because of size and weight.
See transom notes on page 149.
Use structural joining material when necessary or required by code.
The light patterns illustrated apply to removable interior wood grilles, Full Divided Light, Simulated Divided Light, Decorelle 100, 150 and 400 and Finelight
™
Grilles-Between-the-Glass. All removable interior wood grilles will be installed in the units unless otherwise specified. The staggered light patterns illustrated
align with light patterns for the gliding door. Other light patterns are available upon request.
For a metric conversion in millimeters, multiply dimensions in inches by 25.4.
FORMULA FOR COMBINATION DOORS
The overall frame dimension (both width and height) is equal to the sum of the individual unit frame dimensions plus joining material dimension(s).
The overall rough opening (both width and height) is equal to the overall frame dimensions plus 1/4" on all sides.
148 FOR WINDOWS OVER 30 SQUARE FEET OR RATED HIGHER THAN PG50, ONE OF THESE THREE INSTALLATION METHODS IS REQUIRED:
A) THROUGH THE JAMB B) ALUMINUM NAILING FLANGE OR C) INSTALLATION CLIPS.
ADDITIONAL CUSTOM SIZES ARE AVAILABLE. CONTACT YOUR LOCAL SUPPLIER FOR MORE INFORMATION. DRAWINGS ARE NOT TO SCALE.
