ULTIMATE CASEMENT ULTIMATE CASEMENT

EASY WASH MODE FEATURES & OPTIONS

THE CLEANES T DESIGNS AND CLEANES T OPER ATION VERS ATILE DESIGNS, INNO VATIVE IDEA S

With engineering that is only matched by its timeless design, the Ultimate Casement brings light and air
to your home in the easiest, most beautiful ways. Our Ultimate Casement Windows operate in a way
so revolutionary that we’ve patented it, making Marvin the only
®
place to find it. The hardware itself is revolutionary; it allows access
to both sides of the glass from the inside of your home, making
window washing stress and ladder free.

REVOLUTIONARY WASH MODE RETRACTABLE SCREEN MULTI-POINT LOCKING SYSTEM
1. Crank handle twice. When a screen is needed, simply glide the retractable Multi-point locking
screen across the window to put the screen in place. mechanisms make large
2. Push down on the hardware arm, and push the Opened or closed, the screen effortlessly integrates casements easy to operate, and
window away. Then crank arm back.
into the jamb of the window. enhance performance.
3. Swing window all the way open, pulling it across
toward the lock for accessibility to exterior glass. 40"
MAXIMUM SIZE

40" x 96 /8"
1
96 1 / 8 "
36" x 102"

LARGE SIZES - ULTIMATE PERFORMANCE ENDLESS DESIGN OPTIONS
We have developed the most durable A variety of divided lite patterns, including
hardware in the industry, which provides a double hung look make energy-efficient
easy opening and smooth operation casements the perfect replacement
on even the largest casements. window in older homes.
1

WINDOW OPENING CONTROL DEVICE FRICTION LIMITER
Limits the casement sash opening to 4 inches Flip a lever to lock the sash securely in
or less when engaged. The release mechanism place at multiple set angles, allowing you
2 3
allows for operation beyond 4 inches. This option to open your window on windy days.
meets the ASTM F2090-10 standard. Available for push out only.

Note: Marvin exclusive Wash Mode not available on Casement in sizes less than
40 ULTIMATE CASEMENT EASY WASH MODE 20 inches wide, Ultimate French Casement, Ultimate Awning or Round Top Windows. ULTIMATE CASEMENT FEATURES & OPTIONS 41
