WINDOWS

A
A
FEATURES F

CASEMENT & AWNING DOUBLE-HUNG
I E
Frame G Frame
A Frame constructed with a wood core A Frame constructed with a wood core
and a Fibrex composite material exterior. and a Fibrex composite material exterior. H G
®
This construction produces a rigid frame E This construction produces a rigid frame D
and a low-maintenance, durable exterior. and a low-maintenance, durable exterior. C
B
B Wood members are treated with B B C B Wood members are treated with
a water-repellent preservative for a water-repellent preservative for
long-lasting protection and performance. long-lasting protection and performance. F
*
*
C The weatherstripping system D C The dual weatherstripping system
combines an exterior watershed design utilizes a double foam-filled design that
and a foam weatherstrip seal between the G Glass creates a pressure equalization chamber, I Glass
sash and frame, providing a long-lasting, * See page 27 for details. knocking down driving rain and delivering See page 27 for details.
energy-efficient barrier against wind, a long-lasting, energy-efficient barrier
*
water and dust. Hardware against wind, water and dust. Hardware
D A factory-applied rigid vinyl flange Smooth Control Hardware System D Traditional sloped sill design. Sash Lock
helps seal the unit to the structure. Smooth operation provided by a worm gear E For units with White exterior, exterior
Available in a standard design or in drive design makes opening and closing jamb liner is White. For all other exterior
a trim flange design (shown). The trim almost effortless regardless of unit size. colors, the exterior jamb liner is Sandtone.
flange allows for Andersen exterior Also available with an optional split-arm All double-hung windows include lower
®
trim surrounds to be applied in seconds operator that moves the sash away from jamb liner cover/inserts that match the
after window installation.
the frame for easier glass cleaning (not window exterior color.
Sash available on all sizes). Hardware option F A factory-applied rigid vinyl flange Traditional spoon lock design has an
and finish must be specified. Operator
E Fiberglass construction provides handle and cover sold separately. helps seal the unit to the structure. integrated Tilt to Clean feature.
Available in a standard design or in
durable, strong and long-lasting * a trim flange design (shown). The trim
**
®
performance. Finished with a Flexacron Single-Action Casement Lock Sash Options
paint system. This stabilized polyester flange allows for Andersen exterior
trim surrounds to be applied in seconds
paint is electrostatically applied for after window installation.
maximum protection and a lustrous,
low-maintenance finish.
Sash
Traditional architectural style: G Fiberglass construction provides
• Classic chamfer detailing durable, strong and long-lasting *
• The look of mortise-and-tenon joinery Single-action lock easily releases all performance. Finished with a Flexacron
locking points on casement sash while paint system. This stabilized polyester
• Tall bottom rail on casement window the reach-out action eliminates binding paint is electrostatically applied for
aligns with double-hung and picture when closing. The lock handle is offered maximum protection and a lustrous, Cottage Style Reverse Cottage Style
windows for common sight lines in finishes that coordinate with your low-maintenance finish.
F Natural wood interiors are treated specified hardware option. Traditional architectural style:
with a water-repellent preservative for
long-lasting protection and performance. Awning Sash Lock • Classic chamfer detailing
*
Interior stops are fastened using a Awning windows feature dual sash • The look of mortise-and-tenon joinery
compression fit system so there are locks. Hardware style and finish • Tall bottom rail on double-hung window
no nail holes to fill. options are compatible with Andersen
casement windows to ensure aligns with casement and picture
windows for common sight lines
consistency in appearance when
used in combination designs. H Natural wood interiors are treated
with a water-repellent preservative for
long-lasting protection and performance.
*
Interior stops are fastened from behind
so there are no nail holes to fill.

* Visit andersenwindows.com/warranty for details.
** Shown on 400 Series Tilt-Wash double-hung full-frame windows.
“Flexacron” is a registered trademark of PPG Industries, Inc.
