CASEMENT & AWNING WINDOWS

FEATURES

I
Frame Performance Grade (PG) Upgrade
A seamless one-piece, rigid vinyl Casement and awning windows are Performance upgrades are available for select
frame cover is secured to the exterior D H E available with Stormwatch protection. casement and awning sizes, allowing these
®
of the frame to protect the wood frame Visit andersenwindows.com/coastal units to achieve higher performance ratings.
from moisture and maintain an attractive for more details. Performance Grade (PG) Ratings replace
appearance while minimizing maintenance. Design Pressure (DP) Ratings for measuring
C F product performance. For up-to-date
The seamless rigid exterior vinyl cover G
3
extends 1 ⁄8" (35) around the perimeter of performance information of individual
products visit andersenwindows.com.
the unit. This creates a fl ange to help seal Contact your Andersen supplier for availability.
the unit to the structure.
B
Wood frame members are treated
with a water-repellent preservative for EXTERIOR INTERIOR
long-lasting * protection and performance. Hardware
Smooth Control Hardware System
Interior stops are unfi nished pine.
Low-maintenance prefi nished White, The smooth control
Dark Bronze and Black interiors are also hardware system
available. employs a worm White Canvas Sandtone Terratone Pine White
gear drive for easy
Sash operation. Units with
Rigid vinyl encases the entire a split-arm operator
move the sash away
sash — a vinyl weld protects each sash Forest Dark Black Dark Black **
corner for superior weathertightness. It from the frame to Green Bronze Bronze **
maintains an attractive appearance and provide easier glass
cleaning. CXW15, CXW155, CXW16 and Naturally occurring variations in grain, color and texture of wood make each window
minimizes maintenance. one-of-a-kind. All wood interiors are unfi nished unless a prefi nished option is specifi ed.
CXW25 sizes are not available with split-
Wood core members provide excellent arm hardware. Hardware option and fi nish HARDWARE FINISHES
structural stability and energy effi ciency. must be specifi ed. Operator handle and
Flexible bulb weatherstripping or vinyl cover sold separately.
closed-cell foam weatherstripping is factory
installed on the perimeter of the sash. Single-Actuation
Casement Lock
Antique Black Bright Brushed Distressed Distressed
Glass On casement windows, Brass Brass Chrome Bronze Nickel
a single-actuation lock
A glazing bead and silicone provide
superior weathertightness and durability. easily releases all locking
points on casement sash

High-Performance glass while the reach-out action
options include: eliminates binding when Gold Dust Oil Rubbed Polished Satin Stone White
®
• Low-E4 glass closing. The lock handle is offered in Bronze Chrome Nickel
®
• Low-E4 HeatLock glass fi nishes that coordinate with your specifi ed Distressed bronze and oil rubbed bronze are "living" fi nishes that will change with time and use.
• Low-E4 Sun glass hardware option.
™
• Low-E4 SmartSun glass CASEMENT & AWNING HARDWARE OPTIONS †
• Low-E4 SmartSun HeatLock glass Awning Sash Locks
CLA
Tempered glass and other glass options are CLASSIC SERIESSSIC SERIES ™ ESTATE ™
available. Contact your Andersen supplier.
A removable translucent fi lm helps shield
the glass from damage during delivery and
construction and simplifi es fi nishing at
the jobsite.
Stone | White Antique Brass | Bright BrassAntique Brass | Bright Brass
Brushed Chrome | Distressed Bronze
Patterned Glass Awning sash locks provide an added Brushed Chrome | Distressed Bronze
measure of security and weathertightness. Distressed Nickel | Oil Rubbed Bronze
Patterned glass options are available.
See page 10 for more details. Hardware style and fi nish options are Polished Chrome | Satin Nickel
®
compatible with Andersen casement
windows to ensure consistency in TRADITIONAL FOLDING CONTEMPORARY FOLDING
appearance when used in
combination designs.
Black
* Visit andersenwindows.com/warranty for details. Antique Brass | Black | Bright Brass Black | Bright Brass| Bright Brass
** Dark Bronze and Black interiors are only available with Dark Bronze and Distressed Bronze | Distressed Nickel Gold Dust | Oil Rubbed Bronze
Black exteriors respectively. Gold Dust | Oil Rubbed Bronze | Satin Nickel Satin Nickel | Stone | White
† Hardware sold separately. Stone | White
Dimensions in parentheses are in millimeters.
Printing limitations prevent exact duplication of colors and fi nishes. See your Folding handle avoids interference with window decorating treatments.
Andersen supplier for actual color and fi nish samples. Bold name denotes fi nish shown.
